>> Automatic and manual sliding airtight hospital doors

For internal use


Hermetic Seal


Single door


Double door


Lead sheet


Colors

MANUAL DOORS
H-SMITE | H-SMLTE | H-SMVTE

Manual opening door models can be fitted with various types of handles and pulls.

Models designed for operating rooms and positive pressure environments are equipped with a special top guide rail. During door closing, this allows the door panel to lower and slide snugly against the wall and floor, creating an airtight seal.

The weight-bearing wheel set can support and move doors weighing up to 150 kg and comes with an anti-fall device.

The door moves along a track fitted with polyzene guides, which reduces noise, and uses an antistatic toothed belt made of rubber reinforced with Kevlar.


  1. Automation group (automatic only)

  2. Coverage group

  3. Safety sensor in closing (automatic only)

  4. Safety sensor when opening (optional, automatic only)

  5. Digital programmer (automatic only)

  6. Activation devices (automatic only)

  7. Panel (steel, laminate or glass)

  8. Plinth

  9. Horizontal band

  10. Padded or semi-padded (optional)

  11. Closing Feedback

  12. Visual (optional)

  13. Handle (optional)

  14. Internal lead plate (optional only automatic)

Interlock system

Commonly used in hospitals, medical facilities, and private clinics where space segregation and hygiene are paramount, the interlocking system is considered essential.

This system electronically connects two automatic doors, providing systematic access control. One door will only be allowed to open when the other is completely closed. This allows for secure separation of sterile areas and zones, preventing unauthorized access.


Visuals and curtains

Hospital visuals LABEL are made from extruded aluminum frames and laminated safety glass with an 18 mm gap between panes. Available in both frosted and clear glass options, they allow staff to easily see inside the room.

• Simple view type: Manual curtain installation is possible.
Or an electric version.
• RX vision models provide radiation protection equivalent to 2 to 4 mm thick lead.

Sensors and control devices

We offer a wide variety of equipment to ensure maximum efficiency, safety, and ease of access in healthcare facilities. Each door can be customized to suit specific needs and includes the following accessories:

  • Activation and security sensor.

  • Bar-type push buttons, emergency buttons, touch buttons, or elbow buttons.

  • Ignition switch and keypad.

  • Door status indicator light

  • Digital programmer

  • remote control


Lead sheet

Designed for areas requiring extra protection, such as radiology departments and dental clinics, LABEL radiation shielding doors effectively block radiation exposure, creating a safe and secure environment.

The door can be manufactured with either stainless steel sheets or laminate sheets, and can be fitted with lead shielding up to 1 mm thick.

2 mm, 3 mm, or 4 mm.

If it is necessary to see inside a room even when the door is closed, a vision panel can be installed on the door, either with or without a curtain.

There are no curtains.

Glazing

In hospital interior design, glass is widely used in doors, viewing areas, and partitions. Therefore, installing appropriate protective measures is crucial to avoid the risk of injury from broken glass.

LABEL offers glass options in 33.2, 44.2, and 55.2 mm thicknesses, including insulated glass and SMART Glass, which allows for controlled room privacy by switching between transparent and opaque modes.

Glass is available in clear, milky white, and can also be digitally printed or screen-printed with various designs.


Color customization

LABEL offers color customization solutions for all models of doors and automation systems, allowing for seamless integration of design with surrounding architectural elements and aligning perfectly with the customer's brand identity.

The color solutions have been specially developed to provide excellent adhesion and high durability.

The color customization is designed to meet aesthetic and design requirements while maintaining the technical features and performance of the space partitioning system.

Technical specifications of decorative surfaces.

The customization system includes:

  • A standard color palette with over 120 basic colors as per the catalog.

  • Can be produced in specific RAL color shades as required.

  • High-resolution digital printing technology for creating intricate graphic patterns.

  • The screen printing process is certified and complies with fire safety requirements.

  • Installing certified specialty films, specifically for safety purposes.

LABEL Tools App - APP FOR INSTALLERS

Label Tools and Applications for Installers:

  • Control, read, and set all door parameters, with detailed descriptions for each setting.

  • Transfer data easily, quickly, and securely with T-NFC technology.

  • System setup is easy and guided, even with a single command, thanks to the ability to load pre-saved library files or configuration files.


My label - THE APP FOR USERS

With this application, those responsible for door operation and their associates can conveniently and efficiently manage all commands and controls within their area of operation.
